Molecular sieve 3A
WRITER：admin JOIN IN：2015-12-21
CLASSES：Adsorbents
Products Introduction:
XR401 Molecular sieve 3A is an adsorbent used for dehydration of different kind of gases and solution.
Product Information:
XR401 Molecular sieve 3A made by synthetic zeolite powder 3A with selected mineral binder. XR401 Molecular sieve 3A has an effective pore opening of 3? (0.3nm), it can adsorb molecules which diameter less than 3? (0.3nm), molecular sieve mostly used for dehydration of different kind of gases and solution.
Characteristics:
lstable and excellent static and kinetic adsorption capacity
lhigher crush strength
|
Property |
Unit |
Bead |
Pellet |
Note | ||
|
8X12 |
4X8 |
1/16" |
1/8" | |||
|
Static Water Adsorption |
%wt |
≥ 21.00 |
≥ 21.00 |
≥ 20.00 |
≥ 20.00 |
RH50%，25℃ |
|
Crush Strength |
N |
≥ 30.00 |
≥ 80.00 |
≥ 30.00 |
≥ 70.00 |
Average 25 pcs |
|
Crush Strength |
lbs |
≥ 7.00 |
≥ 18.00 |
≥ 7.00 |
≥16.00 |
Average 25 pcs |
|
Bulk Density |
g/ml |
≥ 0.70 |
≥ 0.70 |
≥ 0.65 |
≥ 0.65 |
Settled |
|
Bulk Density |
lbs/ft3 |
≥ 43.00 |
≥ 43.00 |
≥ 40.00 |
≥ 40.00 |
Settled |
|
Loss on Ignition |
%wt |
≤ 1.50 |
≤ 1.50 |
≤ 1.50 |
≤ 1.50 |
575℃,1hr |
|
Loss on Attritioin |
%wt |
≤ 0.10 |
≤ 0.10 |
≤ 0.30 |
≤ 0.30 |
|
|
Particle Ratio |
% |
≥ 97.00 |
≥ 99.00 |
~ |
~ |
|
Application:
1. Drying of unsaturated hydrocarbons (e.g. ethylene, propylene, butadiene)
2. Cracked Gas Drying.
3. Drying of natural gas.
4. Drying of highly polar compounds, such as methanol and ethanol.
5. Static, (non-regenerative) dehydration of insulating glass units, whether air filled or gas-filled.
Storage:
lAvoid moisture, avoid scrolling, throw and sharp shocking during transportation, rainproof facilities should be readied..
lIt should be stored in dry and ventilated warehouse to prevent contamination or moisture.
Package:
|
Type |
Carton |
Durm |
Super sack |
|
Bead |
25 kg/ 55 lb |
150 kg/ 330 lb |
1000kg/ 2200 lb |
|
Pellet |
25 kg/ 55 lb |
150 kg/ 330 lb |
1000kg/ 2200 lb |
