PSR Claus Sulfur Recovery Catalyst
WRITER:admin  JOIN IN:2015-12-21
CLASSES:Alumina Catalyst

Products Introduction:

Sulfur recovery refers to a gas desulfurizing process, or Claus process, which recovers elemental sulfur from gaseous hydrogen sulfide. The sulfur recovery catalyst ( Claus catalyst) recovers, in addition to the sulfur from the gaseous hydrogen sulfide found in raw natural gas, hydrogen sulfide that is contained in by-product gases and derived from refining crude oil and other industrial processes. Our PSR sulfur recovery catalyst(SRU Claus catalyst), with alumina or titania acting as the carrier, is made by adding promoter and caking agent. The catalyst is used in the Claus units for sulfur recovery from acidic gases containing H2S and organic sulfides like COS and CS2, with the total sulfur conversion rate up to 95% or even higher. The sulfur recovery catalyst (SRU Claus catalyst) is commonly applied in the oil refinery, fertilizer, natural gas, petrochemical industries, and others.

Table 1 Xiangrun PSR Series Sulfur Recovery Catalyst(SRU Claus catalyst)

PSR

Catalyst

Chemical Composition

PSR-1

CR

Al2O3

PSR-21(XR401)

CRS

TiO2/Al2O3

PSR-31(XR401@T)

CRS-31

TiO2

PSR-41

AM

FeSO4/ Al2O3

PSR-51

TG

Co-Mo/Al2O3

Table 2 Efficiency of XIANGRUN-PSR Series Sulfur Recovery Catalysts(SRU Claus catalyst)

Processing Type

Catalyst

Filling Reaction

Total Sulfur Conversion Rate (%)

Sulfide Content in Tail Gas (%, V)

Remark

Claus(Grade 2)

PSR-1 Al2O3 PSR-1 Al2O3

First reactor Second reactor

93.8

1.178

Basic type

Claus(Grade 2)

PSR-41 FeSO4/Al2O3 PSR-1 Al2O3PSR-41 FeSO4/Al2O3 PSR-1 Al2O3

First reactor Second reactor

95.5

0.979

Economical type

Claus(Grade 2)

PSR-41 FeSO4/Al2O3 PSR-31 TiO2PSR-41 FeSO4/Al2O3 PSR-31 TiO2

First reactor Second reactor

96.7

0.854

Economical and environment-friendly type

Claus(Grade 2)

PSR-41 FeSO4/Al2O3 PSR-31 TiO2PSR-41 FeSO4/Al2O3 PSR-31 TiO2PSR-31 TiO2

First reactor Second reactor Third reactor

98

0.542

Environment-friendly type

Claus+SCOT

PSR-41 FeSO4/Al2O3 PSR-1 Al2O3PSR-41 FeSO4/Al2O3 PSR-1 Al2O3PSR-51 Co-Mo/Al2O3

First reactor Second reactor Third reactor

>99.8

<300ppmv

Standard type

Note: mark of * refers to the calculation based on H2S content of 60 percent(ν) in acid gas and maximum sulfur conversion rate, as well as by means of the analyzer and detector with H2S/SO2 on-line proportion analysis and control. For the device for high-temperature thermal admix and grade-2 catalytic conversion, the filling volume of PSR-41 catalyst accounts for 1/3~1/2 the bed volume. In case that H2S content in acid gas is less than 40%(ν), the filling volume of PSR-41 catalyst shall account for 1/2~2/3 the bed volume, and the filling volume of PSR-31 catalyst shall account for 1/3~1/2 the bed volume.

 As an experienced Chinese sulfur recovery catalyst manufacturer and supplier, Xiangrun is ISO9001:2000 approved due to its management in line with international standards. Quality is high priority for us at Xiangrun. To accomplish this, we train high quality technical personnel for specialized R&D to ensure reliability of our chemical products. Our high quality competitively chloride removal, adsorbent, and other products are now well received by customers from Britain, Germany, Iran, Jordan, Thailand, Philippines, South Korea, and many others. If you have any inquiries, please contact us.
